Ham Mini Two Way Radio UV-3R 144/430MHz Dual Band UHF / VHF Walkie Talkie

Product Categories
Xiamen Rongxiangrui Imp. & Exp. Co., Ltd
Contact Now

Ham Mini Two Way Radio UV-3R 144/430MHz Dual Band UHF / VHF Walkie Talkie

  • 1
  • 2

Brand Name : baofeng

Model Number : UV-3R

Certification : CE FCC Rohs Certificate

Place of Origin : China

MOQ : 100pcs

Price : USD15.00

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000pcs /month

Delivery Time : 3-5 days

Packaging Details : carton box

Type : Handheld

Output Power : < 5W

Frequency range : 136-174&400-470MHZ

Dimensions : 99x55x30 mm (Excluded Antenna)

Talk Range : 5-10km

Operating Voltage : DC 7.4V

Step Frequency : 2.5/5/6.25/10/12.5/20/25KHz

Contact Now

Ham Mini Two Way Radio UV-3R 144/430MHz Dual Band UHF / VHF Walkie Talkie

Main features:

  • Frequency Range: 136-174/ 400-470MHz

  • Dual-Band Display, Dual Freq. Display, Dual-Standby

  • Output Power: 2 Watts

  • 99 Channels+1 Emergency Channel

  • 50 CTCSS and 104 CDCSS

  • Built-in VOX Function

  • 1750Hz Brust Tone

  • FM Radio (87.0MHz-108.0MHz)

  • LED Flashlight

  • Hight /Low Power Switchable

  • 25KHz/12.5KHz Switchable

  • Emergency Alert

  • Low Battery Alert

  • Battery Saver

  • Time-out Timer

  • Keypad Lock

  • Monitor Channel

  • Channel Step: 5/6.25/12.5/25KHz

Specifications:

GENERAL
Frequency Range 136-174MHz&400-470MHz
Channel Capacity 99 Channels (1 Emergency Channel)
Channel Spacing 5/6.25/12.5/25KHz
Operated Voltage 3.8V
Standard Battery 1500mAh
Battery Life 10 hours
Frequency Stability 2.5ppm(-20 º C ~+60 º C )
Operated Temperature -30 º C ~+60 º C
Antenna Impedance 50 Ω
Dimensions 47*81*23mm
Weight About130g
TRANSMITTER
RF Power Output ≤2W ≥0.5W
Modulation F3E
Spurious Emission 65dB
FM Noise 45dB(N)/42dB(W)
Audio Dsitortion 0.05
Adjacent Channel Power 60dB
Max Frequency Deviation ≤2.5KHz (N)/≤5.0KHz (W)
Frequency Error 500Hz
Modulation Distortion 0.1KHz (300-3000KHz)
Transmitting Current ≤1.4A
RECEIVER
Sensitivity (12dB SINAD) 0.2uV
Squelch Selectivity 0.15uV
Adjacent Channel Selectivity ≥65dB
Background Noise ≤50mV
Spurious Response Rejection -60dB
FM Ham & Noise 48dB(N)/48dB(W)
Audio Power Output 8Ω ≤1.7V
Audio Distortion ≤10%
Receiver Current ≤400mA

Ham Mini Two Way Radio UV-3R 144/430MHz Dual Band UHF / VHF Walkie Talkie

We are according to the country sending Two-way Radio Walkie Talkie charger plug

Full set including:

- 1*UV-3R MINI 2W Walkie Talkie.

- 1*1500mAh Rechargeable battery.

- 1*Detachable antenna.

- 1*Desk charger (100V ~ 240V US / EU / UK / AU plug).

- 1*Blet clip.

- 1*Strap.

- 1*User manual book.
